    Rapid Ref : 32422420010

    Fein 60mm Oversize Jaws for VersaMag Magnetic Vise
    32422420010

    £41.58  EX VAT
     Buy in 3 easy interest free payments of £13.86† with

    Related Items

    FEIN Magnetic Vices FAQs

    Answers to common questions about magnetic vices and their jaws, magnets and welding plates, from how well they hold to using them safely.

    What is a magnetic vice and what is it used for?icon-minus-redicon-plus-red

    A magnetic vice is a clamping vice that sits on a strong magnetic base, so it can be fixed to a steel surface such as a steel plate, a fabrication table or a machine base without bolts or G-clamps. The jaws then hold the workpiece, which might be a pipe, bar or section being drilled, cut, ground or tack welded.

    The magnet and the jaws do different jobs: the magnet keeps the vice in place, and the jaws grip the work. Always check in the manufacturer's manual which surfaces, loads and jobs the vice is designed for.

    What affects how firmly a magnetic base will hold?icon-minus-redicon-plus-red

    A published holding figure is a best-case value, measured with the magnet in direct, flat contact with thick, ground, low-carbon steel. In real use the hold falls if the steel is thin, if the surface is rough, curved, rusty, painted or dirty, or if the magnet is not fully in contact with the steel.

    Any layer between the magnet and the steel acts like an air gap, and the hold drops steeply as the gap grows. For the best result, clean the base and the surface, put the vice on thick, flat steel and always follow the manufacturer's instructions for the model you have.

    Can I use a magnetic vice on a painted, rusty or rough surface?icon-minus-redicon-plus-red

    You can try, but expect less holding power. Paint, rust, mill scale, dirt and rough or uneven surfaces all create tiny air gaps between the magnet and the steel, and even a thin gap reduces the hold. A rough surface can hold far less than a clean, flat, ground one.

    Clean the surface and remove loose swarf and spatter before switching on or placing the vice. If you must work on a coated or uneven surface, treat the rated holding figure as unreliable, test the hold carefully before applying load and use extra support or stops if in doubt.

    Will a magnetic vice resist sideways force when I drill or cut?icon-minus-redicon-plus-red

    Not as strongly as it resists a straight pull. Most real loads on a vice are sideways or twisting, and magnet resistance to sliding depends on friction, so it is usually only a fraction of the straight-pull figure. Drilling, sawing and grinding all create sideways and twisting forces.

    Keep cutting loads light, support the vice against fixed stops where you can, and never rely on the magnet alone to resist a heavy sideways force. Follow the maker's guidance for the job, and stop immediately if the vice shifts or creeps.
