Rapid Ref : 72705861

FEIN KBU 35-2 QW Universal Magnetic Drill 35mm, with 2-Speed Gearbox
72705861

Select Option
Prices From £1812.00 ex VAT

Universal magnetic core drill for up to 35mm

Small and powerful 2-speed universal magnetic core drill with clockwise/anti-clockwise operation and high speed for efficient twist drilling on the construction site.

  • Extremely low-wear tool design with swivel-mounted motor cable protection hose for tough use in industry and manual trades
  • Extremely resilient construction thanks to sturdy machine design with swivel-mounted motor cable protection hose. Designed for tough use in industry and manual trades
  • Perfect power-to-weight ratio thanks to compact, weight-optimised design and FEIN 1100W high-power motor with tacho electronics for high-speed stability for reliable and economical working
  • With clockwise/anti-clockwise operation, electronic speed setting and a 260mm stroke range, this is a universal tool for core drilling, twist drilling, tapping, countersinking and reaming
  • Small with mechanical 2-speed gearbox for twist drilling
  • Simple operating concept avoids mix-ups and can be seen by the user
  • Convenient magnetic holding force display helps the user to reliably position the tool
  • High magnetic holding force thanks to the 2-coil magnet, just 70mm wide
  • Tilt sensor
  • Additional magnetic switch in the drill jig
  • Integrated coolant tank delivers long core drill bit life
  • Feed handwheel can be moved from one side to the other
  • Speed saving "memory function"
  • Personal safety switch

Product Details

Package Includes

1 coolant tank, 1 centring pin, 1 lashing strap, 1 contact guard, 1 swarf hook and 1 case.

Specification

Input: 1,010 W
Output: 550 W
Load speed in speed 1: 130 - 520 rpm
Load speed in speed 2: 400 - 1,600 rpm
Carbide core drill bit max. Ø: 35mm
HSS core drill max. Ø: 35mm
Core drill, drilling depth max.: 50mm
Twist drill max. Ø: 16mm
Tapping: M 14
Countersinking max. Ø: 31mm
Reaming max. Ø: 16mm
Core drill holder: ¾ in Weldon
Changing the core bit: Tool-free
Stroke: 135mm
Total stroke range: 260mm
Cable with plug: 4m

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   Fein KBU 35 Manual Instructions

FEIN Universal Mag Drills FAQs

Straight answers to the questions people ask most when choosing and using high-specification universal magnetic drills.

How do I choose the right size of universal mag drill?icon-minus-redicon-plus-red

Start with the largest hole you need to cut and the thickest material you will drill, then choose a machine whose core capacity and cutting depth comfortably exceed them. Look at the twist drill capacity too, if you need it.

Bigger machines have larger magnets, more power and a heavier body. If you move the machine a lot, balance capacity against weight, and do not buy more machine than your work needs.

What is the difference between a Morse taper and a quick-change fitting?icon-minus-redicon-plus-red

A Morse taper spindle holds twist drills, reamers and tapping adaptors on a tapered shank, which grips by friction and gives accurate running. A quick-change fitting is the common type for annular cutters, with a shank that locks in place and lets you swap cutters fast.

Some machines combine both, with a fitting for cutters and a taper for other tools. Check the spindle type before buying accessories.

Can a universal mag drill be used for tapping?icon-minus-redicon-plus-red

Many universal models support tapping, with a reversing function and slow speed, together with a suitable tapping attachment. Tapping needs slow, controlled speed and the right tap and lubricant, and the machine must be set up for it.

Check that your machine is designed for tapping before using it this way, and follow the manufacturer's instructions. Taps break easily if forced.

How does the magnet affect safe working?icon-minus-redicon-plus-red

The magnet is what holds the machine in place, and its holding force depends on the steel's thickness, flatness and cleanliness. Thin or uneven material, rust, paint, swarf and air gaps all weaken the hold.

Clean the surface and the magnet face, switch on the magnet, and check it is holding before you start the motor. Use a safety strap where the machine could fall, such as overhead or vertical work, and where required by the instructions.
