Angle Grinders FAQs
Straight answers to the questions people ask most when choosing discs for, using and looking after an angle grinder.
What do the disc sizes mean, and which size do I need?

Angle grinders are described by the diameter of the disc they take, and 115mm, 125mm and 230mm are the common sizes. Smaller machines are lighter, easier to control and better for weld dressing, tight spaces and general fabrication. Larger machines remove material faster and cut deeper, but they are heavier, harder to control and need more care.
The disc must always match the grinder and its guard. Never fit a disc larger than the machine and guard are designed for. For most workshop jobs a medium size is the most versatile.
Which disc should I use for cutting, grinding and finishing?

Use the disc made for the job. Thin cutting discs are designed to cut with their edge and should not be used for side grinding, because they are not built to take side loads and can break. Thicker grinding discs remove metal with their face. Flap discs blend and finish, leaving a smoother surface while still removing material, and wire brushes clean off rust, scale and paint.
Discs are also made for particular materials, such as steel, stainless steel or stone, so read the label. For stainless steel, use discs marked as suitable and kept for stainless only, so you do not contaminate the surface with particles from carbon steel.
How do I fit or change a disc safely?

Switch the grinder off and unplug it, or remove the battery, and wait for the disc to stop. Check the new disc for cracks and damage, and make sure its size, thickness and maximum speed suit the machine. Fit the guard, then the disc on its flange, then tighten using the correct key or the spindle lock, as the manual describes.
The disc must sit flat and central with nothing trapped behind it. Never press the spindle lock while the motor is running. After fitting, run the machine at full speed with the guard in place, pointing away from people and standing out of line with the disc, for the time given in the manual, before starting work.
Why is the guard so important, and how should I set it?

The guard protects you from sparks and fragments, and from the pieces if a disc breaks. It also keeps the exposed part of the disc as small as possible. It must be fitted every time, and positioned so the closed side faces you and only the part of the disc needed for the job is exposed. Do not remove it to reach into a corner, because a disc that bursts is a serious hazard.
Guards made for cutting are often different from those for grinding, so check you have the correct one for the work. Check that the guard locks firmly after you adjust it, and replace any that is damaged or missing before using the machine.
