Rapid Ref : 72381861000

FEIN KFH 17-15 R 1700W 15mm Beveller - 230v
72381861000

£2296.85  EX VAT
SSP Suggested Selling Price = £3377.73  YOU SAVE £1080.88
 Buy in 3 easy interest free payments of £765.62† with

Beveller up to 15mm

Universal beveller with booster and spring technology for perfectly preparing welded seams.

  • Milling performance improved by 30 - 80% and vastly reduced vibrations thanks to new booster technology
  • Spring technology: absorption of rotational forces and therefore improved operational safety from low vibration working
  • FEIN ErgoGrip: unique, ergonomic concept of two-handed operation for fatigue-free working (patent pending)
  • Extensive user protection features include soft start, restart protection, jam monitoring and electronic overload protection
  • Efficient quick-change cutter system for minimal interruptions
  • Effective material removal requiring little force
  • Extensive range of accessories for various materials such as steel, stainless steel and non-ferrous metals
  • Above-average service life of the indexable inserts due to 8-fold or 16-fold usability

Product Details

Package Includes

1 tool (without milling head, without guide roller, without indexable tips), 6 x clamping screws, 1 x copper paste, 1 socket head wrench 5mm, 1 x TX 15 Torx screwdriver, and 1 plastic carrying case.

Specification

Input: 1,700W
Output: 1,000W
Speed, no load: 2,300 - 7,500rpm
Max. bevel length at 45°: 15mm
Max. bevel height at 45°: 10.6mm
Bevel angle: 30° / 37.5° / 45° / 60°
Radius: 2 / 3 / 4mm
Milling head configuration: 3x2 KX tip
Support plate diameter: 137mm
Cable with plug: 4m
Weight according to EPTA: 6.40Kg

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   FEIN KFH 17-8/15 Manual

FEIN Bevellers FAQs

Answers to common questions about choosing and using bevelling machines for weld preparation and edge finishing.

What bevel angle should I prepare for a butt weld?icon-minus-redicon-plus-red

The angle that matters is the included angle, because it has to allow the correct torch or electrode angle to reach the joint. A single bevel normally needs a wider angle than a double-V joint, where both plates are prepared. Experience has shown that about 45 degrees on a single bevel joint is usually sufficient.

Your weld procedure or drawing may call for a different angle, a root face or a particular gap, so always work to that rather than a general rule. Check which angles your machine can produce on its data plate and in the manual.

Why machine a bevel rather than leave a thermally cut edge?icon-minus-redicon-plus-red

High-temperature cutting leaves a heat-affected zone along the cut edge, and oxy-fuel cutting creates the widest of these. Thermally cut edges can also be rough, oxidised and locally hardened, which is why many procedures call for the face to be ground or machined before welding.

A milling-type beveller removes metal by cutting it cold, without adding heat to the edge, and usually leaves a more even surface than a thermally cut edge. Your weld procedure or code decides what edge condition is acceptable and whether further cleaning is needed, so always check it.

How can I reduce hand-arm vibration when using a beveller?icon-minus-redicon-plus-red

Regular exposure to vibration from hand-held power tools can damage the hands and arms. Early signs include tingling and numbness in the fingers, and fingers going white and then red and painful as they recover. Report these early.

To reduce the risk, limit the actual trigger time, service the machine and its cutting tips as the maker recommends, and do not grip harder than needed. The vibration figure in the manual helps your risk assessment, and the right tool for the job usually means less time spent on it.

How should I look after a beveller?icon-minus-redicon-plus-red

Work equipment should be kept in efficient working order and good repair, and the HSE advises following the maker's maintenance instructions. Before each use, check the cable, plug or battery, guards and housing for damage, and make sure the cutting tips are secure and the head is free of packed-in swarf. After use, brush out the swarf and wipe the machine down.

Store it in its case in a dry place. Do not use a machine with damaged parts, and isolate it from the power supply or remove the battery before changing tips or making adjustments. Have faults dealt with by a competent person.
