Rapid Ref : 72704361241

FEIN KBM 65 U Universal Magnetic Drill 65mm 72704361241

£2123.75 EX VAT

SSP Suggested Selling Price = £2316.82 YOU SAVE £193.07

Select Option

Metal core drilling unit up to 65mm

Powerful and very high-performance 2-speed universal magnetic core drill with clockwise/anti-clockwise operation, MT3 tool mounting, fine adjustment and maximum functionality for flexible working in the workshop.

Extremely low-wear tool design with swivel-mounted motor cable protection hose for tough use in industry and manual trades
Perfect power-to-weight ratio thanks to the compact, weight-optimised design and FEIN 1300W high-power motor with tacho electronics for high-speed stability for reliable and economical working
With clockwise/anti-clockwise operation, electronic speed setting and a 315mm stroke range, this is a universal tool for core drilling, twist drilling, tapping, countersinking and reaming
Fine adjustment of the drill spindle for convenient tool alignment
MT3 tool mounting
Simple operating concept avoids mix-ups and can be seen by the user
Convenient magnetic holding force display helps the user to reliably position the tool
High magnetic holding force
Integrated coolant tank delivers long core drill bit lives
Feed handwheel can be moved from one side to the other
Speed saving "memory function"
Personal safety switch

Product Details

Package Includes

1 coolant tank, 1 centring pin, 1 lashing strap, 1 contact guard, 1 swarf hook, 1 drift key and 1 case.

Specification

Input: 1,300 W W
Output: 730 W
Load speed in speed 1: 120 - 240 rpm
Load speed in speed 2: 260 - 520 rpm
Tool holder: MK 3
Carbide core drill bit max. Ø: 65mm
HSS core drill max. Ø: 45mm
Core drill, drilling depth max.: 50mm
Twist drill max. Ø: 25mm
Tapping: M 20
Countersinking max. Ø: 50mm
Reaming max. Ø: 25mm
Core drill holder: ¾ in Weldon
Changing the core bit: Tool-free
Stroke: 145mm
Total stroke range: 315mm
The adjustment range for drill jigs: 6mm
Swivel range for drill jigs: 7°
Cable with plug: 4m
