    Rapid Ref : 63502309000

    FEIN Saw Blade for Mild Steel, BIM 733 T10 MS (Pack of 3)
    63502309000

    £44.36  EX VAT
    SSP Suggested Selling Price = £56.51  YOU SAVE £12.15
     Buy in 3 easy interest free payments of £14.79† with

    Band saw blade for metal and plastic.

    Suitable for use in the following materials: steel, non-ferrous metals and plastics and/or composite materials with a yield strength < 1400 N/mm². Has an impressive blade for low-vibration and good sawing progress with a tooth spacing of 1.8 to 2.5 mm.

    Specification

    Material: BiM(BiMetal)
    Width: 0.35mm
    Length: 733mm
    Height: 13mm
    TPI: 10 / 14

    Related Items

    FEIN ABAS 18-63 AS Saw Blades FAQs

    Straight answers on choosing, running in and looking after bi-metal blades for portable metal-cutting band saws.

    How do I choose the right number of teeth per inch for the metal I am cutting?icon-minus-redicon-plus-red

    The usual rule is that enough teeth should be in the cut at the same time to support the metal as the blade passes through it. Most guides give a baseline of around five to seven teeth in the cut, and some accept as few as three as a minimum.

    In practice that means a finer pitch (more teeth per inch) for thin sections and a coarser pitch (fewer teeth per inch) for thick or solid sections. Too coarse and teeth can chip and the blade can bounce; too fine and the chips can overload the gaps between the teeth. Treat any chart as a starting point and check the blade maker's selection guide.

    Which pitch should I use for thin-wall tube, angle and sheet?icon-minus-redicon-plus-red

    For thin sections, the thickness of the wall matters, not the overall size of the tube or profile. A thin wall generally needs a finer pitch so that several teeth are always engaged and none of them drops into the open hollow and catches.

    If you move up to a thicker or solid section, switch to a coarser blade. A fine blade used on thick material tends to fill its tooth gaps with swarf, which slows the cut and overheats the blade. When a job mixes thin and thick sections, a variable-pitch blade is often the more forgiving compromise.

    How do I break in a new blade?icon-minus-redicon-plus-red

    New teeth have a very sharp edge that can chip easily. Breaking the blade in lets that edge wear to a fine radius that holds up under cutting forces, and the blade then usually cuts straighter and lasts longer.

    In general, start the first cuts with noticeably lighter feed pressure than normal, keep the cut steady without vibration, and raise the pressure gradually over several cuts until you reach the normal rate. Softer metals usually allow a bigger reduction at the start than harder ones. The exact amount depends on the blade, the metal and the saw, so follow the blade maker's instructions.

    Why does my blade stop cutting properly in stainless steel?icon-minus-redicon-plus-red

    Stainless steel can harden at the cut face if the blade rubs instead of cutting. This usually happens when the feed pressure is too light, the blade is already dull, the blade has too fine a pitch or the speed is too high. Once the surface has hardened, even a sharp blade struggles.

    Use a blade made for the material, keep the feed steady and firm enough that the teeth bite and produce proper chips, and avoid pausing with the blade running against the work. Follow the blade maker's recommended feeds and speeds, and use cutting fluid if the maker advises it.
