Rapid Ref : 71321161000

FEIN ABLK 18 1.6 E AS Cordless 18V Nibbler (Bare Unit)
71321161000

£464.00  EX VAT
SSP Suggested Selling Price = £632.73  YOU SAVE £168.73
 Buy in 3 easy interest free payments of £154.67† with

Cordless nibbler up to 1.6 mm

Compact and curve-compatible nibbler for roof and façade construction. Precise cuts in trapezoid and corrugated sheet metals and profiles.

  • 66 m cutting capacity (in 0.8 mm sheet metal) with one battery charge (5 Ah).
  • Cutting direction setting can be changed in 45° steps up to 360° using tool-free pivoting cutting head.
  • Optimum handling due to extremely slim gearbox head.
  • 1.5 m/min cutting speed for excellent work progress.
  • Variable cutting speed due to electronically adjustable speed control.
  • Brief overlapping area up to 2.6 mm.
  • Rotating punch for a service life which is now up to 30 % longer.
  • Proven MultiMaster motor with outstanding performance and stability.
  • QuickIN quick change system for die and punch.
  • Low operating costs. Punch and die are replaced independently of one another.
  • Compatible with AMPShare/Bosch Professional 18 V batteries.
  • Maximum work progress with AMPShare 18V storage batteries: COOLPACK 1.0 technology ensures a longer storage battery life compared with batteries without COOLPACK technology and therefore makes longer operating periods possible. ECP protects the storage battery against overload, overheating and total discharge.
  • Ideally equipped for every job. Mobile working with the L-BOXX system.

Product Details

Package Includes

1 die (30109141003) fitted, 1 punch (63602048004) fitted, 1 cutting head (301095154007) mounted, 1 socket head wrench 6mm, 1 tool case (L-BOXX 136).

Specification

Battery voltage: 18 V
Battery compatibility: Li-ion / ProCORE Li-ion
Battery interface: 18 V AMPShare
Strokes 850 - 1,350 rpm
Cutting speed: 1.5 m/min
Steel up to 400 N/mm²: 1.6mm
Steel up to 600 N/mm²: 1.0mm
Steel up to 800 N/mm²: 0.7mm
Non-ferrous metals up to 250 N/mm²: 2.5mm
Cutting width: 5mm
Immersion Ø with dire: 22mm
Rad. of smallest curve (inside/outside): 30/35mm
Weight w/o storage battery: 1.71kg

Brochures & Manuals

Related Items

FEIN Nibblers & Shears FAQs

Practical answers on choosing, using and looking after cordless nibblers and sheet metal shears.

How thick a sheet can a cordless nibbler or shear cut?icon-minus-redicon-plus-red

There is no single figure, because the rated thickness depends on the tensile strength of the material as well as the tool. Harder, stronger steel can only be cut in thinner sheet than mild steel, and soft metals such as aluminium can usually be cut a little thicker.

The maker publishes a capacity table for each model, usually listed against several tensile strength bands. Many nibblers also have a gauge groove on the die holder, and the rule is not to attempt material that will not fit into it. Always work within the table on your tool's data plate or in its manual, and treat the rating as a maximum rather than a target.

Can these tools cut stainless steel and aluminium?icon-minus-redicon-plus-red

Nibblers and shears of this type are normally intended for sheet steel and stainless sheet steel, but stainless is tougher, so the maximum thickness is lower than for mild steel. Check the capacity table for your model and expect more vibration and wear when cutting stainless.

Aluminium and other soft metals can be cut, usually in a greater thickness than steel, but the chips tend to stick to the punch and die. Lubricating the cutting line with oil, as your manual describes, helps reduce this. Keep the cutting area free of other metals so you do not contaminate stainless sheet with steel particles.

What is the best way to cut corrugated or profiled sheet?icon-minus-redicon-plus-red

A nibbler is generally recommended for corrugated, trapezoidal and other profiled sheet, because it can follow the ridges and valleys without bending the profile out of shape. Shears can struggle where the sheet changes direction.

Support the sheet so it does not flex or rattle as you cut, and clamp it where you can. The cutting edges leave sharp burrs on profiled sheet, so wear cut-resistant gloves and take care when handling off-cuts. Cutting with a tool designed for the job also avoids the heat and coating damage that an abrasive cutting wheel can cause to galvanised or painted sheet.

What is the difference between slitting shears and sheet metal shears?icon-minus-redicon-plus-red

Both cut with blades, but they work differently. Slitting shears take out a thin strip as they go, which keeps the sheet flat and the edge clean, and they are generally used on thinner sheet. Sheet metal shears slice straight through the sheet, usually handle somewhat thicker material and cut long straight lines quickly, but they tend to bend or curl the sheet on one side of the cut.

Slitting shears are the better choice where flatness and a tidy edge matter, such as visible panels or ducting. Check each tool's rated thickness for the material you use.
