Rapid Ref : 71300661000

FEIN ABLS 18 1.6 E AS Cordless 18V Sheet Metal Shears (Bare Unit)
71300661000

£443.00  EX VAT
SSP Suggested Selling Price = £604.09  YOU SAVE £161.09
 Buy in 3 easy interest free payments of £147.67† with

Cordless sheet metal shears up to 1.6 mm

Ergonomic, curve-compatible cordless sheet metal shears for cutting and trimming thin sheets.

  • 221 m cutting capacity (in 0.8 mm sheet metal) with one battery charge (5 Ah).
  • Outstanding ergonomics through compact and simple construction for optimal mobility of the shears.
  • Four-fold reversing blade for clean and burr-free cutting with low operating costs.
  • Good curve precision with low sheet-metal distortion.
  • Perfect for trimming and cutting.
  • Unrestricted view of the cutting line.
  • Proven MultiMaster motor with outstanding performance and stability.
  • Compatible with AMPShare/Bosch Professional 18 V batteries.
  • Maximum work progress with AMPShare 18V storage batteries: COOLPACK 1.0 technology ensures a longer storage battery life compared with batteries without COOLPACK technology and therefore makes longer operating periods possible. ECP protects the storage battery against overload, overheating and total discharge.
  • Ideally equipped for every job. Mobile working with the L-BOXX system.

Product Details

Package Includes

1 plunger blades and bench blade, 1 socket head wrench 2mm, 1 socket head wrench 3mm, 1 hand guard, 1 tool case (L-BOXX 136)

Specification

Battery voltage: 18 V
Battery compatibility: Li-ion / ProCORE Li-ion
Battery interface: 18 V AMPShare
Strokes 2,200 - 3,500 rpm
Cutting speed: 6 - 9 m/min
Steel up to 400 N/mm²: 1.6mm
Steel up to 600 N/mm²: 1.2mm
Steel up to 800 N/mm²: 1mm
Non-ferrous metals up to 250 N/mm²: 2mm
Rad. of smallest curve: 15mm
Weight w/o storage battery: 1.44kg

Brochures & Manuals

Related Items

FEIN Nibblers & Shears FAQs

Practical answers on choosing, using and looking after cordless nibblers and sheet metal shears.

Can these tools cut stainless steel and aluminium?icon-minus-redicon-plus-red

Nibblers and shears of this type are normally intended for sheet steel and stainless sheet steel, but stainless is tougher, so the maximum thickness is lower than for mild steel. Check the capacity table for your model and expect more vibration and wear when cutting stainless.

Aluminium and other soft metals can be cut, usually in a greater thickness than steel, but the chips tend to stick to the punch and die. Lubricating the cutting line with oil, as your manual describes, helps reduce this. Keep the cutting area free of other metals so you do not contaminate stainless sheet with steel particles.

How do I cut curves and internal cut-outs with a nibbler?icon-minus-redicon-plus-red

Nibblers are the usual choice for curves because the cutting head is compact and the sheet is not forced to one side. Every model has a minimum cutting radius, so check the manual for the tightest curve it will follow, and move the tool gently in the cutting direction rather than pushing hard.

For an internal cut-out you normally cannot start at an edge. Drill or punch a starting hole large enough for the cutting head to fit into, then nibble outwards to your marked line. Mark the line clearly and use the notch or cutting line indicator on the die holder to follow it.

What is the best way to cut corrugated or profiled sheet?icon-minus-redicon-plus-red

A nibbler is generally recommended for corrugated, trapezoidal and other profiled sheet, because it can follow the ridges and valleys without bending the profile out of shape. Shears can struggle where the sheet changes direction.

Support the sheet so it does not flex or rattle as you cut, and clamp it where you can. The cutting edges leave sharp burrs on profiled sheet, so wear cut-resistant gloves and take care when handling off-cuts. Cutting with a tool designed for the job also avoids the heat and coating damage that an abrasive cutting wheel can cause to galvanised or painted sheet.

What is the difference between slitting shears and sheet metal shears?icon-minus-redicon-plus-red

Both cut with blades, but they work differently. Slitting shears take out a thin strip as they go, which keeps the sheet flat and the edge clean, and they are generally used on thinner sheet. Sheet metal shears slice straight through the sheet, usually handle somewhat thicker material and cut long straight lines quickly, but they tend to bend or curl the sheet on one side of the cut.

Slitting shears are the better choice where flatness and a tidy edge matter, such as visible panels or ducting. Check each tool's rated thickness for the material you use.
