Welding process: TIG DC, constant or pulsed, with or without Oscillation, AVC and wire feeder
Input power: Single phase, 115/230V ± 15% - 50/60 Hz
Main fuse: 16 A @220V - 20 A @115V
Opened circuit voltage: 94V
Insulation class: H
Protection class: IP 23 S
Welding current: 3 to 220 A @220V - 3 to 160 A @115V
Duty cycles (230V): 40°C: 100% - 165 A / 60% - 190 A / 35% - 220 A
Duty cycles (110V): 40°C: 100% - 120 A / 60% - 145 A / 35% - 160 A
Motor controls: Encoder and Tachospeed motors
Display / Recording: Welding current, Arc Voltage, electrode angular position, welding and wire speed
Connectivity (Documentation, Updates): 1 x RS232
Dimensions (L x W x H): 490 x 195 x 400 mm
Weight: 15,4 kg
Standard: EN 60974-1 / EN 60974-10
