Kemppi MasterTig 535 AC/DC GM TIG Welder Power Source with 7" TFT Control Panel - 400v, 3ph MT535ACDCGM

£8907.36 EX VAT

Buy in 3 easy interest free payments of £2969.12^† with

Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

Far from the Ordinary

Kemppi presents the master of AC and DC TIG welding in the new MasterTig, which sets new standards in weld quality, usability and power efficiency. The latest MasterTig models were designed to fit the welders specifications and needs with choices of control panels, remote controls and transports. Thanks to its stylish, practical and robust design, the MasterTig has the capacity and structure to withstand the hardest knocks and impacts of everyday welding life. This package comes equipped with the appropriate control panel to achieve the machine’s full capacity. In this case, the machine is supported with an AC/DC membrane control panel.

Product Details

Double Pulse

Double Pulse combines alternative pulse cycles to provide 30% faster welding speed and 20% less heat input. Helping to lower distortion and weld costs. Ideal for DC hand welding and offers a superb weld seam appearance.

Optima AC

A customised AC TIG waveform that combines the best of the traditional sine and square waveforms - and adds a touch of magic for the optimal AC welding experience. Depending on the application you are free to choose either sine, square, or Optima AC, the quiet option.

MicroTack

MicroTack offers fast and accurate tacking with minimum heat input in both DC and AC TIG welding. Making it ideal for multiple, repetitive tacking on thin sheet applications, where consistency and appearance are vital. MicroTack can be set between 1 to 5 repeat pulse cycles or continuous cycle mode. The welding current level is set independently and the arc cycle time is selected between 1 to 200ms.

iTEC

iTEC is engineered ignition technology for reliable arc starts. Particularly useful with long torch extensions for site welding or precise thin materials and low current applications, you can set the variable spark force energy.

Auto Pulse

Easy and convenient, the only value to adjust is the welding current itself. Auto Pulse is ideal for DC current applications.

7" TFT Control Panel

Protected by a 3mm armour shield plate, the 7" TFT control panel is both impact and scratch resistant, allows fast and accurate parameter setting with WeldAssist, and offers 99 memory channels per process to save the best parameters or WPS values.

Key benefits

Weld assist can set the right parameters and settings to fit the welders needs to complete an easy and productive welding application, making the MasterTig a lot faster set-up than previous models.
Welding speed has been increased thanks to the Double Pulse function which accelerates travel speed in DC applications and lower heat input.
Noise levels have been reduced for the MasterTig models so welders concentrate quietly on the quality of their welds.

Superb user experience

Structure was constructed from durable, energy-absorbing recyclable plastics, incorporating a slick impact bridge body.
UI control panels were designed to allow easy, fast and accurate parameter settings. Panels are also impact and scratch resistant.
No longer the need to replace cables due to repairs thanks to Bluetooth-incorporated wireless remotes. Makes your welding easy and stress-free.

Enhanced welding

Experience fast and accurate welding thanks to MicroTack. A revolutionised feature designed for multiple and repetitive tacking on thin sheet applications.
The iTec features an engineered ignition technology tool designed for a reliable arc start that is useful for large torch extensions.
A weld time clock features enable workers to establish weld cycle measurements and job data records.

This MasterTig machine applies to IEC 60974-1,-3,-10.
