  • 72232060  FEIN GSZ 8-90 PEL 410W Slow Speed Die Grinder, for Stainless Steel Grinding & Polishing
  • 72232060  FEIN GSZ 8-90 PEL 410W Slow Speed Die Grinder, for Stainless Steel Grinding & Polishing
Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : 72232060

FEIN GSZ 8-90 PEL 410W Slow Speed Die Grinder, for Stainless Steel Grinding & Polishing
72232060

Select Option
Prices From £288.00 ex VAT

Straight Grinder 9,000/min

Ergonomic, powerful die grinder for stainless steel processing with high plunge depth for grinding and polishing in especially difficult-to-reach spots.

  • Long narrow neck allows the tool to plunge a long way into workpieces (e.g. grinding inside pipes)
  • User protection features include blockage monitoring, restart protection, soft start and electronic overload protection
  • Innovative collets with all-round flange to protect the workpiece and prevent the wrench sliding off during tool changes
  • POWERtronic tacho-electronics for enormous power, power reserve and exceptional speed stability under load
  • Removable rubber collar bearing cover
  • Motor and electronics protected against metal dust
  • Variable speed allows different tools to be used

Product Details

Package Includes

1 collet Ø 6 mm, Jaw spanner SW13 and Jaw spanner SW17.

Specification

Input: 710 W
Output: 410 W
Speed, no load: 2,500 - 9,000 rpm
Grinding wheel for max. Ø: 50mm
Collet for max. Ø: 8mm
Collar Ø: 43mm
Max. cutter diameter: 12mm
Cable with plug: 4m
Weight according to EPTA: 1.80Kg

Brochures & Manuals

BROCHURES & MANUALS
   View Brochure
   Fein GSZ 4/8/11 Manual Instructions

FEIN Long Neck Die Grinders FAQs

Answers to common questions about choosing and using long neck die grinders for deep, internal and hard-to-reach grinding work.

When should I choose a long neck die grinder rather than a short one?icon-minus-redicon-plus-red

Choose a long neck when the work is deep inside a part or structure and the body of a standard grinder would get in the way, for example inside bores, ports, box sections, pipe interiors or recessed castings. The extended neck moves the cutting point away from the motor housing.

If the work is in the open, a shorter, more compact grinder is usually easier to handle because it is better balanced. Think about how far in you need to reach and how much room you have around the job, then check the maker's data for neck length and the largest accessory it takes.

Which accessories can I fit, and how do I choose between wheels, burrs and cutters?icon-minus-redicon-plus-red

Die grinders take small mounted grinding points, rotary burrs and cutters, abrasive sleeves, flap wheels and polishing accessories, up to the maximum sizes in the maker's data. The accessory must suit the tool, so check its shank and its speed rating before you fit it.

As a general guide, grinding wheels and points are used on hard materials such as steel, while rotary cutters suit softer materials such as aluminium, brass, copper and wood. Using a grinding wheel on a soft material can overload it and may cause it to break up. Use each accessory only for the jobs its maker recommends.

What is overhang on a mounted point, and why does it matter on a long neck grinder?icon-minus-redicon-plus-red

Overhang is the length of spindle that sticks out between the collet and the abrasive point. The safe speed for a mounted point depends on its shape and size, the spindle diameter and the overhang. A long exposed spindle can bend, and an overspeed or bent spindle can throw the point, which has caused serious eye and face injuries.

Keep the overhang as short as practical, and do not exceed the maximum speed the maker gives for that point and overhang. A long neck grinder does not change this rule: it only moves the collet further from the motor. If you need unusually long spindles, ask the accessory maker for guidance.

Does the speed rating on the accessory matter, and how does variable speed help?icon-minus-redicon-plus-red

Yes. The speed marked on the accessory should be at least as high as the no-load speed of the grinder, otherwise the accessory can shatter in use. Never fit an accessory with a lower rating than the maximum speed of the tool.

Variable speed lets you bring the grinder down to a speed that suits the accessory and the material, which gives you more control and helps limit heat. Lower speeds are generally used for larger wheels, polishing accessories and heat-sensitive materials, higher speeds for small burrs. Follow the speed guidance for each accessory and the grinder's manual.
