Rapid Ref : 71380262000

FEIN AKFH 18-5 AS 18V Cordless Beveller (Bare Unit)
71380262000

£899.45  EX VAT
SSP Suggested Selling Price = £1322.73  YOU SAVE £423.28
 Buy in 3 easy interest free payments of £299.82† with

Cordless beveller up to 5mm

Powerful cordless beveller for perfectly preparing subsequent coatings for flexible jobs in the workshop and on the construction site.

  • For the production of bevels and radii on flat materials, sheet metals and containers, of inner and outer edges, contour shapes and for rounding off holes
  • High sanding capacity requiring little force and infinitely variable speed setting for different materials
  • Ergonomic thanks to low weight and compact design
  • FEIN PowerDrive motor delivers good performance and long service life
  • Extensive user protection features include soft start, restart protection, jam monitoring and electronic overload protection
  • Compatible with all 18V AMPShare ProCORE batteries and chargers for even more power and flexibility. Also suitable for 18V Bosch Professional cordless devices
  • ProCORE Li-Ion battery with high-power cells, charge status indicator and “Electronic Cell Protection” (ECP). ECP protects against overload, overheating and total discharge
  • COOLPACK 2.0 technology delivers a 135% longer battery life and therefore makes longer operating times possible
  • Extensive range of accessories for various materials such as steel, stainless steel and non-ferrous metals
  • Above-average service life of the indexable inserts due to 8-fold or 16-fold usability
  • Ideally equipped for every job. Mobile working with the L-BOXX system

Product Details

Package Includes

1 tool including 45 milling head (without guide roller, without indexable tips), 3 x clamping screws SX, 1 x copper paste, 1 x 4mm socket head wrench, 1 x TX 15 Torx screwdriver, and 1 plastic tool case (L-BOXX 238).

Specification

Battery voltage: 18V
Battery compatibility: Li-ion / ProCORE Li-ion
Battery interface: 18V AMPShare
Speed, no load: 2,400 - 7,500rpm
Max. bevel length at 45°: 5mm
Max. bevel height at 45°: 3.5mm
Bevel angle: 45°
Radius: 1.2 / 2.5mm
Milling head configuration: 3x SX tip
Support plate diameter: 98mm
Weight without storage battery: 2.52Kg

Brochures & Manuals

Related Items

FEIN Bevellers FAQs

Answers to common questions about choosing and using bevelling machines for weld preparation and edge finishing.

What bevel angle should I prepare for a butt weld?icon-minus-redicon-plus-red

The angle that matters is the included angle, because it has to allow the correct torch or electrode angle to reach the joint. A single bevel normally needs a wider angle than a double-V joint, where both plates are prepared. Experience has shown that about 45 degrees on a single bevel joint is usually sufficient.

Your weld procedure or drawing may call for a different angle, a root face or a particular gap, so always work to that rather than a general rule. Check which angles your machine can produce on its data plate and in the manual.

Why machine a bevel rather than leave a thermally cut edge?icon-minus-redicon-plus-red

High-temperature cutting leaves a heat-affected zone along the cut edge, and oxy-fuel cutting creates the widest of these. Thermally cut edges can also be rough, oxidised and locally hardened, which is why many procedures call for the face to be ground or machined before welding.

A milling-type beveller removes metal by cutting it cold, without adding heat to the edge, and usually leaves a more even surface than a thermally cut edge. Your weld procedure or code decides what edge condition is acceptable and whether further cleaning is needed, so always check it.

How can I reduce hand-arm vibration when using a beveller?icon-minus-redicon-plus-red

Regular exposure to vibration from hand-held power tools can damage the hands and arms. Early signs include tingling and numbness in the fingers, and fingers going white and then red and painful as they recover. Report these early.

To reduce the risk, limit the actual trigger time, service the machine and its cutting tips as the maker recommends, and do not grip harder than needed. The vibration figure in the manual helps your risk assessment, and the right tool for the job usually means less time spent on it.

How should I look after a beveller?icon-minus-redicon-plus-red

Work equipment should be kept in efficient working order and good repair, and the HSE advises following the maker's maintenance instructions. Before each use, check the cable, plug or battery, guards and housing for damage, and make sure the cutting tips are secure and the head is free of packed-in swarf. After use, brush out the swarf and wipe the machine down.

Store it in its case in a dry place. Do not use a machine with damaged parts, and isolate it from the power supply or remove the battery before changing tips or making adjustments. Have faults dealt with by a competent person.
