MIG/MAG digital inverter PATON ProMIG-500-15-4-400V W MAXwire is a professional device designed for MIG/MAG welding, MMA and TIG DC welding. The device ProMIG-500-15-4-400V W MAXwire implemented a fully digital method of control, due to which its multifunctionality and wide possibilities for precise adjustment of welding modes are ensured. Increased load duration on the nominal current up to 500?, allows working with any electrodes with a diameter from 1.6 mm to refractory 8 mm, as well as semi-automatic welding with a solid wire with a diameter from 1,2 to 2,0 mm. Thanks to the double-case design, the current source can be easily separated from the wire-weeding unit, significantly increasing the mobility and convenience of operation in MMA and TIG modes.
Specification
| Mains Voltage: |
380/400 3ph |
| Welding Current Range: |
16 - 500A |
| Duty Cycle: |
500A at 70%, 420A at 100% |
| Maximum Power Consumption: |
29kVA
|
| Dimensions (L x W x H): |
-
|
| Weight (with accessories): |
87.2kg |
| Protection Class: |
IP23
|
Perfect For
- Metallurgy
- Metalworking
- Shipbuilding
- Ship repair
