Tecna 50 kVA Linear Action Column Pneumatic Operated Spot Welder w/ TE101 Processor 4666

£8519.00 EX VAT

SSP Suggested Selling Price = £12170.00 YOU SAVE £3651.00

Buy in 3 easy interest free payments of £2839.67^† with

Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.

The stationary ergonomic frame designed by TECNA helps to facilitate the operator's work. The pneumatic commands and the compressed air pressure gauge have been placed at the top for easier reading and adjustment.

Key Features

Chrome-copper electrode holders for long life and heavy-duty service, designed for straight and angled fitting
Water-cooled epoxy resin coated transformer
Water-cooled arms, electrodes, and electrode holders
Microprocessor control unit TECNA TE101
USB port for data storage (only with TE550)
The air operated lubrication free cylinder eliminates oil mist
Protected filter assembly with gauge
Two-stage electric foot control for clamping the welding pieces in the correct position before welding
Pre-connected for additional electric foot pedal for the direct recalling of welding program No.2. This function is helpful when different kinds of welding are to be performed on the same piece
Arms: gap 280mm, adjustable depth 320mm
Adjustable electrodes stroke for max. working rate
