TECNA-4643 Tecna 25 kVA Column Pedal Operated Spot Welder w/ TE101 Processor
    Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

    Rapid Ref : TECNA-4643

    Tecna 25 kVA Column Pedal Operated Spot Welder w/ TE101 Processor TECNA-4643

    Prices From £4319.00 ex VAT
    Select Option

    The stationary ergonomic frame designed by TECNA helps to facilitate the operator's work. The control unit has been positioned on the front of the machine to allow the operator to view the welding data even during the working cycle.

    Key Features

    • Arms adjustable in length, allowing better working flexibility
    • Chrome-copper electrode holders for long life and heavy-duty service, designed for straight and angled fitting
    • Adjustable electrode stroke
    • Epoxy resin coated transformer
    • Water-cooled transformer, arms, and electrodes
    • Microprocessor control unit TECNA TE101
    • Adjustable electrode force; a microswitch starts the welding cycle when the desired pre-set value is reached. The foot pedal is adjustable in length

    Product Details

    Nominal power @ 50%: 25 kVA

    Maximum welding power: 68 kVA

    No load secondary voltage: 4.6 V

    Maximum short circuit current: 18 kVA

    Maximum welding current on steel: 14.4 kA

    Thermal current 100%: 3800 A

    Supply voltage 50Hz: 400 V

    Cables section L=10m: 16mm2

    Cables section L=30m: 16mm2

    Delayed fuses: 50 A

    Net weight (approximately): 145Kg

    Brochures & Manuals

    BROCHURES & MANUALS
       View Brochure
