The TECFEED 350i compact is robustly constructed in a reinforced moulded case to give a fully enclosed wire feed unit which is well sealed against the elements. Due to its rugged construction, this is ideal for all site welding in harsh environments & also is very portable. This wire feed unit is designed to run off virtually any constant current or constant voltage power source, including MMA, TIG, MIG and engine driven type DC power sources. The wire feed unit requires no additional supplies, only welding cable connections, and can run positive or negative polarity, giving very good performances with solid or flux cored wires.
- Arc voltage sensing wire speed control for arc stability
- 4 roll drive system for the best feeding of wire
- Burnback control
- Normal trigger, and trigger latch functions
- Contactor and gas valve fitted as standard
- Takes a 5Kg reel of wire
- Welding current range - 50 to 350 amps
- Will work with input voltages of between 20 - 110V, (Welding down to 15V). Optional amps and voltage digital readout, and optional flow gauge can be fitted
Size L=460mm, W170=mm, H=360mm, 8Kg approx.
