Rapid Ref : 9873252 Mfr Ref : SP9873252

Kemppi Outer Protection Plate - 60mm x 110mm
SP9873252 9873252

Name: Kemppi Outer Protection Plate - 60mm x 110mm
SKU: 9873252
Price: 1.27 GBP

£1.27 EX VAT

SSP Suggested Selling Price = £1.49 YOU SAVE £0.22

Lens dimensions: 60mm x 110mm.

Alfa e60P Helmet Parts FAQs

Replacement lenses, fittings and comfort parts for a passive welding helmet, and how to work out the right one.

Does a welding helmet protect me from welding fume?

No. A standard helmet protects the eyes, head and neck from arc radiation and spatter. It is designed for use where ventilation is sufficient, and a fresh-air helmet is recommended where ventilation is poor. The HSE says the best option for arc welders is a powered or supplied-air respirator that combines respiratory, eye and face protection.

Where fume controls such as local exhaust do not give adequate control, suitable respiratory equipment should be added, and it must work with the other protective equipment, such as the helmet. Ask your supplier or safety adviser, and follow your risk assessment.

How do I clean the helmet and lenses without damaging them?

Blow loose dirt and dust off first, then wipe the helmet with a damp cloth wetted with mild soapy water, and dry it with a clean cloth. Maker instructions say not to use solvents or strong cleaning solutions. Plastic plates scratch easily, so handle them carefully.

Inspect the shell, headband, filter and plates for cracks, pitting or scratches each time you use the helmet, and replace anything damaged, because a damaged part reduces protection. Do not put the helmet down on a hot surface such as a hot weld, and keep it somewhere clean and dry. Follow the manual for your model.

How should I set up the headband so the helmet sits comfortably?

Adjust the height and girth of the headband for comfort. Set the band fairly low so the helmet stays firmly in place, with the sweatband a little above your eyebrows and ears, and tighten it with the adjusting wheel to suit your head.

Then set the helmet angle so that its lower edge is near your chest while welding, where protection is best, and adjust the pivot tightness so a raised helmet stays up but drops when you nod. If it strikes your chest as it falls, it is too loose or set too close to your face. Replace the headband if it is cracked or no longer holds its setting.

What do small fittings such as springs and adjuster sets do?

A filter retaining spring holds the filter and protection glass in the helmet's hatch frame, so a bent, weak or lost one can let parts shift. How it is released and refitted depends on the helmet, so follow the manual and make sure it is seated properly before use.

Adjuster sets are the parts, such as the adjustment plate and screws, that set the helmet angle and how tightly it pivots against the headband. They wear with use, so replace them when they are loose, cracked or no longer hold their setting. These parts are specific to a helmet family, so identify the right one from the manual's parts list or the old part rather than by appearance.

See all 6 questions for this category
