Rapid Ref : 4,075,233P

Fronius - TPS 600i Standard Water-Cooled MIG Package, with MTW 700i MIG Torch - 400v, 3ph
4,075,233P

Name: Fronius - TPS 600i Standard Water-Cooled MIG Package, with MTW 700i MIG Torch - 400v, 3ph
SKU: 4,075,233P
Price: 16207.90 GBP

Click here to see what's included

£16207.90 EX VAT

Buy in 3 easy interest free payments of £5402.63^† with

Additional items to consider

The 600i is one of the Fronius TPS/i series and has been praised by many as a universal genius.

Its design and inner workings have been revolutionised starting from scratch to provide the welding system of the future. All welding features have been massively improved from previous models and the communication between machine and man has been enhanced to a higher level of intelligence. Thanks to the system’s expertly crafted components and integrated design, performance rates are ensured and guaranteed.

Features

Plain-text display – The graphical user interface has been improved to provide and enhance the necessities to work sufficiently in the high demands of the welding environment. Wearing gloves will not get in the way thanks to its superb operation system, making the machine easy to work from and certifying efficient stability
Fronius System Connector – The FSC provides a safe secure connection for all types of media sources. Tasks such as locking hose packs are simply accomplished with this feature, resulting in a quick cycle of interchangeable parts
Plug & Weld - Thanks to a specially designed automatic component recognition system, this feature alerts the user of any incompatibility with connections made from outer sources to the power source
SpeedNet – The SpeedNet provides speedier communication between components with a 100 Mbit/s data bus. The recovery of all system statuses is accessed in real-time, all thanks to a reliable and precise process control feature

Package includes

4,075,233 – Fronius TPS 600i MIG Welder Power Source
4,100,612 – Fronius I-kit Cooling Filter FK 5000
4,049,032 – Fronius WF 30i Wire Feeder
4,047,871 – Fronius HP 120i Water-cooled Connection Hosepack
4,035,967 – Fronius MTW 700i Water-cooled MIG Torch
4,077,020 – Fronius TU Car4 Pro
43,0004,4998 – Fronius Ground Cable 120i 4m
44,0350,5202 – Fronius MTW 700i Wear Part Kit
44,0001,1408 – Fronius Feeder Roll U 1.4-1.6mm
44,0350,5122 – Fronius Basic Kit Gas-cooled & Water-cooled 5m
4,048,017,633 – Fronius CU 1400i Cooling Unit

Brochures & Manuals

BROCHURES & MANUALS

View Brochure

Fronius TPS 320i 400i 500i 600i TPS 400i LSC ADV Operating Instructions

What's Included

	Fronius - MTW 700i Watercooled MIG Torch - FSC/UD/4.5m/45°/LED
	Fronius - HP 120i Watercooled Connection Hosepack 1.2m
	Fronius - CU 1400i Pro/MC Cooling Unit
	Fronius - WF30i 4R /W /FSC Wire Feeder
	Fronius - TPS 600i MIG Welder Power Source, with No Welding Package - 400v, 3ph
	Fronius - TU Car 4 Pro

	Fronius - I-Kit Cooling Filter FK 5000
	Fronius - Ground Cable 120i PC /4m
	Fronius - Feeder Roll U 1.4 - 1.6mm
	Fronius - BK Fe ø1.6 /G/W/5m
	Fronius - Wear Part Kit MTW700i ø1,6

415v MIG Welders FAQs

Straight answers to the questions people ask most when choosing a three-phase MIG welder for workshop and production use.

Who needs a three-phase MIG welder?

Three-phase machines suit fabrication shops, production lines, engineering workshops and anyone welding thicker material or for long periods. A three-phase supply carries more power for a given current per phase, so these machines can give higher output with a steadier load on the supply.

If you only have a single-phase supply, you are limited to single-phase machines.

What is the difference between 400v and 415v on these machines?

In practice, very little. Older documents and some machine labels refer to 415v, while the current nominal figure for a UK three-phase supply is usually given as 400v. Machines are normally designed to work within a tolerance either side of their rated input, but the allowed range depends on the maker and the model.

Check the data plate and the manual for the supply the machine accepts, compare that with the measured supply at your site, and ask a qualified electrician if you are unsure.

Do I need special wiring or a fuse rating to install one?

Yes, it needs a three-phase connection with the correct cable size and protection for the machine's input current, installed by a competent electrician. The manual states the recommended supply cable and fuse or breaker rating.

Do not connect a machine to a circuit that has not been checked for the load. Poor supply causes tripping, overheating and unreliable welding.

Air-cooled or water-cooled: which should I choose?

Air-cooled torches are simpler and need no extra equipment, and suit many general jobs. Water-cooled torches carry higher current for longer without overheating, so they suit heavy, continuous or production welding, but they need a cooler and a little more upkeep.

Choose according to the current and the duty cycle you will use.
