The Magic Weld 200 is a portable petrol welder generator with the capability of welding 4mm electrodes. It is powered by a Honda GX270 air cooled petrol engine with an innovative permanent magnet alternator giving 200 amps DC welding output. The Magic Weld 200 is available as machine only package or a site ready package (Wheel Kit and welding cables, see related items)
Features
- Engine shut down (oil pressure)
- 110v auxiliary power
- Power optimiser
- Protective frame
- Economiser (Auto Idle)
Specification
Current range: 20 - 200A
Duty Cycle: 200A - 60%
Open circuit voltage: 70V
Engine: Honda GX 270
Output: 6.3kW (8.5 HP)
Speed: 3600 rpm
Fuel Consumption (welding 60%): 1.5 l/h
Tank Capacity: 5.3l
Running time (welding 60%): 3.5h
Protection: IP23
Dimensions: 610mm x 490mm x 520mm
Dry weight: 57kg
